Targas 52 Indoor Ceiling Fan - TG52ESP3
52" Targas in Espresso w/ Mahogany/Teak Blades
Modern and minimalist, the Targas 52" features a sleek tri-blade design, 4-speed, reversible motor with dimmable LED lighting and hard-wired speed and light control.
- Hard Wired, 4 Speed Control Included
- Custom Reversible Targas 52" Blades Included Dark Oak/Walnut
- Tri-Mount (Flat, Semi-flush) or Angled Ceiling up to 23°
- Suitable for Indoor only
- Integrated 22 Watt LED Light Kit (Dimmable)
- Standard, 4-Speed Reversible Motor
- 6 inch Downrod Included
- JA8/Title24 Compliant
- Energy Guide 1844 CFM, High Speed 3011 CFM
| Base Model Number | TG52xxx3 |
|---|---|
| Feature 8 | JA8/Title24 Compliant |
| Feature 7 | 6 inch Downrod Included |
| Feature 6 | Standard, 4-Speed Reversible Motor |
| Feature 5 | Integrated 22 Watt LED Light Kit (Dimmable) |
| Feature 4 | Suitable for Indoor only |
| Feature 3 | Tri-Mount (Flat, Semi-flush) or Angled Ceiling up to 23° |
| Feature 2 | Custom Reversible Targas 52" Blades Included Dark Oak/Walnut |
| Feature 1 | Hard Wired, 4 Speed Control Included |
| Feature 9 | Energy Guide 1844 CFM, High Speed 3011 CFM |
| 2nd DR Blade to Ceiling (in.) | 6.12 |
| Blade to Ceiling (in.) | 11.79 |
| Canopy Height (in.) | 2.40 |
| Canopy Width (in.) | 5.12 |
| A: | 16.73 |
| A: 2nd Downrod | 11.37 |
| B: | 11.79 |
| B: 2nd Downrod | 6.12 |
| C: | 10.24 |
| D: | 5.12 |
| E: | 8.96 |
| F: w/ Light Kit | 11.39 |
| F: w/o Light Kit | 8.96 |
| G: | 6.44 |
| H: | 5.12 |
| H: | 10.24 |
| I: | 8.96 |
| Downrod Length (in.) | 6 |
| Blade to Ceiling (in.) | 6.44 |
| Height (in.) | 11.39 |
| Housing Size | 10.24 |
| Housing Height | 8.96 |
| Height (in.) | 16.73 |
| 2nd DR Height (in.) | 11.37 |
| Blade Sweep Opt (in.) | 52 |
| Blades | 3 |
| Blade Pitch (deg) | 10.50 |
| Motor Size (MM) | 153x15 |
| Amps at High Speed | 0.44 |
| Watts (Hi Speed) | 57.05 |
| Energy Guide Watts | 34 |
| Energy Guide CFM | 1844 |
| Energy Guide CFM_Watts | 55 |
| Energy Guide Est. Yearly Energy Cost | 9 |
| High Speed (CFM) | 3010.76 |
| Low Speed (CFM) | 522.64 |
| Shipping Weight (lbs.) | 17.53 |
| Carton Size (CU FT) | 2.13 |
| Length (in.) | 22.32 |
| Blade Material | MDF |
| Blade Sweep (in.) | 52 |
| Blades Included | Included |
| Blade Width (in.) | 5.47 |
| Bulb CCT | 3000 |
| Bulb Wattage | 22 |
| Bulb Base | Integrated LED |
| Bulbs | 1 |
| Bulb Size | Integrated LED |
| Bulb Type | LED |
| Shipping Height (in.) | 11.73 |
| Shipping Length (in.) | 22.87 |
| Shipping Width (in.) | 11.22 |
| Child Styles | Urban, Retro, Industrial, Fusion |
| Collection | Targas 52 |
| Control Status | Included |
| Control Method | Wall Control (hard-wired) |
| Control Types Included | CM-7W-LED |
| CRI | 90 |
| Dimmable | Yes |
| Energy Star | No |
| Fan Dimensions Image | tri-mount-dim-dia.png |
| Material | Glass |
| Inner Pack Qty | 1 |
| Leadwire Length (in.) | 76 |
| Light Kit | Integrated |
| Light Kit Adaptable | No |
| Light Kit Features | Integrated Light Kit (1-16 Watt LED Bulb Included) |
| Light Kit Location | Integrated |
| Light Kit Options | Integrated |
| Lumens | 1150 |
| Motor Diameter (in.) | 153 |
| Motor Height (in.) | 15 |
| Motor Material | Silicon Steel |
| Speeds | 3 |
| Motor Type | AC |
| Mounting Location | Indoor |
| Mounting Method | Tri-Mount (Flat, Angled, Semi Flush) |
| No. Downrods Included | 1 |
| No. Shipping Boxes | 1 |
| Parent Styles | Contemporary, Midcentury/Modern, Vintage, Transitional |
| Product Code | 111 |
| Product Code Description | Indoor Ceiling Fan with Blades Included |
| Product Type | Ceiling Fan (Blades Included) |
| Reverse Location | Upper Housing |
| Reverse Method | Slide Switch |
| Reversible Blades | Yes |
| Rooms | Living, Bedroom, Gameroom, Office |
| RPM 1 | 198.32 |
| RPM 2 | 143.52 |
| RPM 3 | 112.81 |
| Safety Rating | cETLus |
| Shipping Type | Small Parcel |
| Shipping Weight (lbs.) | 17.53 |
| UPS Oversized | No |
| Specs 1 | 52" Blade Sweep Option; 3 Blades; 10.5 Degree Blade Pitch |
| Specs 2 | Motor Size (MM): 153 x 15 |
| Specs 3 | AMPS (Hi Speed): 0.45 |
| Specs 4 | Airflow (Cubic Feet Per Minute): 5433.19 |
| Specs 5 | Watts (Hi Speed): 54.01 |
| Specs 6 | Airflow Efficiency (CFM Per Watt): 100.6 |
| Voltage | 120V/60Hz |
| Warranty | Limited Lifetime Warranty |
| Glass or Shade Color | Frost White |
| A: | 16.73 |
|---|---|
| A: 2nd Downrod | 11.37 |
| B: | 11.79 |
| B: 2nd Downrod | 6.12 |
| C: | 10.24 |
| D: | 5.12 |
| E: | 8.96 |
| F: w/ Light Kit | 11.39 |
| F: w/o Light Kit | 8.96 |
| G: | 6.44 |
| H: | 5.12 |
| H: | 10.24 |
| I: | 8.96 |
| Downrod Length (in.) | 6 |
